● Hot
Pluggable SFP MSA package
● SFF-8472
and IEEE 802.3z compliant
● Telcordia
GR-468-COREcompliant
● Up to
550m for 50/125 µm MMF
● Multi
rate 1.0625Gb/s~1.25Gb/s
● 850nm
VCSEL and PIN receiver
● SFI
high speed electrical interface
● 2-wire
serial interface with Digital Diagnostic
● +3.3V
power supply
● Power
consumption less than 1W
● Operating
case temperature: -5 to +70 ℃
● Duplex
LC Receptacle
● ROHs-6
compliant
| 应用场景 | 1000MBase-SX |
|---|
| 波长范围 | 850nm |
|---|---|
| 数据传输率 | 1.0625 ~ 1.25Gb/s |
| 发射器 | VCSEL |
| 接收器 | PIN |
| 输出功率 | -8 ~ -4 |
| 灵敏度 | ＜-20dBm |
| 距离 | 550m |
| 工作温度范围 | -40 ~ +85℃ |
|---|
