● Hot
Pluggable SFP+ MSA package
● SFF-8431,
SFF-8432 compliant
● IEEE802.3ae
10Gbase-SR/SW compliant
● Up to
300m transmission on OM3 MMF
● Multi
rate 10.3125Gb/s~10.5Gb/s
● 850nm
VCSEL and PIN receiver
● SFI
high speed electrical interface
● 2-wire
serial interface with Digital Diagnostic
● +3.3V
power supply
● Power
consumption less than 1W
● Operating
case temperature: -5 to 70 ℃
● Duplex
LC Receptacle
● ROHs-6
compliant
| 应用场景 | 10GBase-SR,10G Fiber |
|---|
| 波长范围 | 850nm |
|---|---|
| 数据传输率 | 10.3Gb/s |
| 发射器 | VCSEL |
| 接收器 | PIN |
| 输出功率 | -7.3 ~ -1 |
| 灵敏度 | ＜-11dBm |
| 距离 | 300m |
| 工作温度范围 | -5 ~ +70℃ |
|---|
