| Qty | 1 | 2 -10 | 11 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥4,280.00 | ￥4,194.40 | ￥4,066.00 | ￥3,937.60 | ￥3,852.00 |
| gain | 43dB min |
|---|---|
| Gain flatness | ±1.5dB typ |
| Limit voltage | 30V |
| P1dB | 43dBm min |
| OIP3 | 55dBm@输出为10W间隔250KHz的双音频 |
| Input reflection coefficient | -15dB typ |
| Output reflection coefficient | -10dB typ |
| working voltage | 24-28 V |
| Working current | 3.0A typ@在输出为Psat /26V |
| Connector 1 Series | SMA |
| Connector 1 Gender | 母 |
| Connector 2 Series | SMA |
| Connector 2 Gender | 母 |
| Power | +5dBm |
| Frequency Range | 1.8GHz–2.6GHz |
|---|
| Storage temperature | -55°C ～ 125°C |
|---|---|
| Temperature Range | -40 ~ 55℃ |
| Weight | 无 |
|---|
