| Qty | 1 | 2 -10 | 11 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥1,600.00 | ￥1,568.00 | ￥1,520.00 | ￥1,472.00 | ￥1,440.00 |
| gain | 35dB typ |
|---|---|
| P1dB | 33dBm typ |
| Gain flatness | ±1.0dB |
| working voltage | 24V |
| Working current | 200mA |
| Connector 1 Series | SMA |
| Connector 1 Gender | 母 |
| Connector 2 Series | SMA |
| Connector 2 Gender | 母 |
| Power | 无 |
| Frequency Range | 1～520MHz |
|---|
| Storage temperature | -40℃～100℃ |
|---|---|
| Temperature Range | -40~70℃ |
| Weight | 68g |
|---|
