| Qty | 1 | 2 -10 | 11 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥1,500.00 | ￥1,470.00 | ￥1,425.00 | ￥1,380.00 | ￥1,350.00 |
| frequency range | 1.8–1.9GHz |
|---|---|
| gain | 30dB typ |
| P1dB | 5dBm typ |
| Gain flatness | ±1.5dB typ |
| Noise figure | 2.0dB typ |
| working voltage | 12.0 V |
| Working current | 80mA |
| Input standing wave | 1.5 :1 |
| output vswr | 1.5 :1 |
| working temperature | -20°C ～70°C |
|---|---|
| Storage temperature | -55°C ～ 100°C |
