| Qty | 1 | 2 -10 | 11 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥5,800.00 | ￥5,684.00 | ￥5,510.00 | ￥5,336.00 | ￥5,220.00 |
| frequency range | 21.0–24.0GHz |
|---|---|
| gain | 28.0dB typ |
| P1dB | 19.0dBm typ |
| Gain flatness | ±2.0dB typ |
| OIP3 | 30.0dBm |
| working voltage | 12.0 V |
| Working current | 200mA |
| Input standing wave | 2.0 :1 |
| output vswr | 2.0 :1 |
| working temperature | -20°C ～70°C |
|---|---|
| Storage temperature | -55°C ～ 100°C |
