All Categories >Power Dividers/Combiners/Couplers/Hybrids >Hybrids >180 Degree Hybrid Coupler >SMA 180 Deg. Hybrid Coupler,2-18GHz,20W

SMA 180 Deg. Hybrid Coupler,2-18GHz,20W

Model:GHC-180-020180 191679ID:

Price List
$ US Dollar | ¥ 人民币

Qty 1 2 -5 6 -20 21 -50 51+
Price ¥--- ¥--- ¥--- ¥--- ¥---
Price: ¥---
Qty
- +
Leadtime: 16-21 days
Add to Cart Inquiry Now

SMA 180 Deg. Hybrid Coupler,2-18GHz,20W

Description
Peak Power Max. 3kW
CW Power Max. 20W
Impedance, Ohms 50Ω
Conn.Type SMA(F)
Electrical Specifications
Phase Bal. Max. ±9°
Amp.Bal. Max. ±0.7dB
Isolation Min. 16dB
Frequency Range 2 ~ 18G
VSWR 1.6
Insertion Loss 2.8dB
Environmental Specifications
Temperature Range -35 ~ +105℃
MECHANICAL CHARACTERISTICS
Outline Dim. 77.2x34.3x12.7mm
