| Qty | 1 | 2 -10 | 11 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥--- | ￥--- | ￥--- | ￥--- | ￥--- |
F-type 20dB Bi-Directional Coupler,700-2500MHz
| Input Power | 25W |
|---|---|
| Impedance, Ohms | 75Ω |
| Conn.Type | F |
| Mainline Loss | 0.5dB |
|---|---|
| Frequency Flatness Max. | ±0.95dB |
| Directivity Min. | 15dB |
| Nominal Coupling | 20±0.8dB |
| Frequency Range | 700-2500MHz |
| Output Return Loss | 23dB |
| Input Return Loss | 23dB |
| Temperature Range | -55°C~+100°C |
|---|
