2.92mm 10dB Directional Coupler,20-40GHz,20W

Model:GDC-10-200400 105197ID:

Price List
$ US Dollar | ¥ 人民币

Qty 1 2 -5 6 -20 21 -50 51+
Price ¥--- ¥--- ¥--- ¥--- ¥---
Price: ¥---
Qty
- +
Leadtime: 16-21 days
Add to Cart Inquiry Now

2.92mm 10dB Directional Coupler,20-40GHz,20W

Description
Conn.Type 2.92mm(F)
Impedance, Ohms 50Ω
CW Power Max. 20W
Peak Power Max. 3kW
Electrical Specifications
Frequency Range 20 ~ 40G
Nominal Coupling 10±0.8dB
Main VSWR Max. 1.6
Coupling VSWR Max. 1.6
Directivity Min. 11dB
Frequency Flatness Max. ±0.8dB
Insertion Loss 1.8dB
Environmental Specifications
Temperature Range -55 ~ +125℃
MECHANICAL CHARACTERISTICS
Outline Dim. 31.8x12.7x15.8mm
