2.92mm Female End Launch Connector, 2 Hole Flange, Hole Spacing 8.9mm,DC-40GHz

Model:2.92-KFD0605 101623ID:

Price List
$ US Dollar | ¥ 人民币

Qty 1-10 11 -50 51 -200 201 -500 501+
Price ¥77.80 ¥76.24 ¥73.91 ¥71.58 ¥70.02
Price: ¥77.80 /pcs
Qty
- +
Leadtime: 4-7 days
Add to Cart Inquiry Now

2.92mm Female End Launch Connector, 2 Hole Flange, Hole Spacing 8.9mm,DC-40GHz


Description
Connector 1 Series 2.92mm
Connector 1 Gender Female
Connector 1 Impedance 50 Ohms
Connector 1 Polarity Standard
Connector 1 Body Material Stainless Steel
Interface Type For PCB
Mount Method 2 Hole Flange
Body Style Straight
Electrical Specifications
Frequency Range DC-40G
VSWR ≤1.15
Environmental Specifications
Temperature Range -55~+165℃
