| Qty | 1 | 2 -5 | 6 -20 | 21 -50 | 51+ |
|---|---|---|---|---|---|
| Price | ￥--- | ￥--- | ￥--- | ￥--- | ￥--- |
SMA 30dB Directional Coupler,0.5-8GHz,20W
| Peak Power Max. | 3kW |
|---|---|
| CW Power Max. | 20W |
| Impedance, Ohms | 50Ω |
| Conn.Type | SMA(F) |
| Nominal Coupling | 30±0.8dB |
|---|---|
| Frequency Range | 0.5 ~ 8G |
| Frequency Flatness Max. | ±0.7dB |
| Directivity Min. | 18dB |
| Coupling VSWR Max. | 1.3 |
| Main VSWR Max. | 1.3 |
| Insertion Loss | 0.7dB |
| Temperature Range | -35 ~ +105℃ |
|---|
| Outline Dim. | 111.8x12.7x17.8mm |
|---|
