2 Way SMA Power Divider,0.3-18GHz,20W

Model:GPD-2-003180 100197ID:

Price List
$ US Dollar | ¥ 人民币

Qty 1 2 -5 6 -20 21 -50 51+
Price ¥5,800.00 ¥5,684.00 ¥5,510.00 ¥5,336.00 ¥5,220.00
Price: ¥5,800.00 /pcs
Qty
- +
Leadtime: 8-15 days
Add to Cart Inquiry Now

2 Way SMA Power Divider,0.3-18GHz,20W

Description
Conn.Type SMA(F)
Impedance, Ohms 50Ω
CW Power Max. 20W
Peak Power Max. 3kW
Electrical Specifications
Frequency Range 0.3 ~ 18G
Input VSWR Max. 1.5
Output VSWR Max. 1.5
Isolation Min. 17dB
Amp.Bal. Max. ±0.4dB
Phase Bal. Max. ±4°
Insertion Loss 2.4dB
Environmental Specifications
Temperature Range -35 ~ +105℃
MECHANICAL CHARACTERISTICS
Outline Dim. 216.5*25.8*12.7mm
